The Vacuum Bag Filler
Vacuum bag filling was originated by Modern Machine Shop 60 years ago and has been the industry leader by which all vacuum bagging is measured. The accomplishments in the field of vacuum packaging go back to the pre-World War II era when can, box, drum, and explosive filling were extensively used for military applications. These processes have been modified and refined through the years and we now can supply a full line of vacuum filling services:
- Kraft bags
- Poly bags
- Tyvek bags
- Boxes
- Fiber & metal drums
- Bulk bags
- Special shape containers
- Densifying
Also available are material supply hoppers, transfer units, screeners, and special application engineering.
________________________________________________________________________________________________________________________
Features of the Modern Machine Shop Vacuum Bag Filler
- Fills Kraft or vapor barrier bags, in either paper, plastic or Tyvek(TM)
- Welded aluminum shroud with hand-adjustable bottom and side liners
- Steel vacuum filter tank built in for faster reaction times and easy operation
- Control valves and electronics are encased in a NEMA 12 enclosure NEMA 4 and explosion-proof enclosures are also available
- Self-cleaning and recycling mechanism for cleanliness and reduction of product waste
- Four-program selector switch is provided for flexibility, allowing several products to be filled on the same machine
- Programmable electronic scale with optional RS-232 port
- Automatic scale zeroing for more accurate filling
- Operator controls are clearly marked pushbutton and selector switches to simplify machine operation
________________________________________________________________________________________________________________________
Standard Vacuum Pump Assembly
We supply a vacuum pump and motor which are mounted on a steel frame complete with guards. A water solenoid valve, flow control valve, 2″ check valve and in-line water separator are also provided. The vacuum tank is built in to the bagging machine, close to the filling chamber, which provides quick reaction times and excellent control to the filling sequences.
- 15 HP, 220/440 Volt, 3 Phase motor. Special voltage ratings are also available
- Single or two-stage vacuum pump provides up to 29″ Hg of vacuum
- Liquid-ring pump design minimizes wear, and reduces maintenance costs and downtime
- Quiet and dependable operation
________________________________________________________________________________________________________________________
Specifications
| Vacuum Bagger | Vacuum Pump | |||
|---|---|---|---|---|
| Dimensions | 51″ L x 27.5″ W x 81″ H | Shipping weight | Approx. 1,200# | |
| Floor weight | Approx. 900# | Motor rating | 15 HP, 3phase, TEFC 220/440 VAC. Other voltages supported | |
| Shipping weight | Approx 2000# | Pump design | Liquid ring | |
| Bag sizes | Suit customer specifications | Vacuum | Up to 24″ Hg for single stage models. Up to 29″ Hg for two- stage models. 160 CFM | |
| Accuracy | +/- 2 to 4 oz. at the 2-sigma level depending on product and atmospheric conditions (density, moisture, etc.) | Water Supply | 7 – 9 GPM, 1/2″ pipe | |
| Scale | Programmable process meter with opt. Analog, RS-232, or RS-485 output |  Click for a larger view |
||
| Logic controller | Digital logic controllers selected to meet customers needs and existing standards | |||
| Load cell | Strain gage, made to our specifications | |||
| Valve sizes | 5 1/2″ to 9″ | |||
| Power | 120 VAC, 5 A; other voltages also supported | |||
| Control air | 80 psig with in-line regulation and lubrication | |||
